High Performance Fiber Optics - SP Series

High Performance Type- SP Series

Overview Products Lineup Specs Dimensions Model

Through-beam｜Screw-fixed Mount

Type		Fiber Unit Length (Diameter) Ambient Temperature	Bending Radius (mm)	Sensing Distance (mm)*1	Optical Axis Diameter (mm)	Minimum Detectable Object	Model / Weight
Dimension / Shape
M3	Thread	1m cuttable（Ø1.3×2） -40℃ ~ +50℃	R25	0~550	-	ø0.005	SP-236FA 12g

	Hexagonal Type	1m cuttable（Ø1.3×2） -40℃ ~ +70℃	R2	0~450			SP-236TZ 12g

M4		2m cuttable（Ø2.3） -20℃ ~ +50℃	R1	0~3600	ø2.3		SP-271TZ 22g

		2m cuttable（Ø2.2） -40℃ ~ +50°C	R2	0~3100	ø1.13		SP-278TZ 43g

		1m non-cuttable -40℃ ~ +50°C	R10	0~1800			SP-278TG 43g

	Thread	2m cuttable (ø2.2) -40℃ ~ +70°C	R25	0~3600	ø1		SP-28F 21g

		2m cuttable (ø1.3) -40℃ ~ +70°C	R4	0~2200			SP-279 9g

		2m cuttable (ø2.2) -40℃ ~ +50°C	R4	0~3600	ø1.13		SP-278 25g

			R0.5				SP-278V 25g

		1m non-cuttable -40℃ ~ +50°C	R10	0~1800			SP-278G 39g

M6		2m cuttable（ø2.2） SP-272Z：-40℃ ~ +50°C SP-272：-40℃ ~ +70°C	R2	0~3600	ø1.5		SP-272Z 25g

			R25				SP-272 25g

Type		Fiber Unit Length (Diameter) Ambient Temperature	Minimum Bending Radius (mm)	Sensing Distance (mm)*1	Optical Axis Diameter (mm)	Model / Weight
Dimension / Shape
M4	Hexagonal Type	2m cuttable (ø2.2) -40℃ ~ +60°C	R2 Flex-proof	0~3600	Emitter: ø1 Receiver: ø3.2	SP-R278TZ 25g

		1m non-cuttable -40℃ ~ +60°C	R10 SUS	0~1800		SP-R278TG 43g

	Thread	2m cuttable (ø2.2) -40℃ ~ +60°C	R2 Flex-proof	0~3600		SP-R278 21g

		2m cuttable (ø2.2) -40℃ ~ +60°C	R25	0~3600		SP-R28F 21g

		1m non-cuttable -40℃ ~ +60°C	R10 SUS	0~1800		SP-R278G 41g

Through-beam, Cylindrical

Dimension	Fiber Unit Length (Diameter) Ambient Temperature	Bending Radius (mm)	Sensing Distance (mm)*1	Optical Axis Diameter (mm)	Minimum Detectable Object	Model / Weight

ø1.0	50cm non-cuttable -40℃ ~ +50°C	R10	0~380	ø0.265	ø0.005	SP-259 8g

	1m cuttable (ø1.0) -40℃ ~ +50°C	R2 Flex-proof High Flex Typ	0~590	ø0.5		SP-259U 4g

ø1.5	1m cuttable (ø1.0) -40℃ ~ +70°C	R4 High Flex Typ	0~1200	ø0.7		SP-260 3g

	1m cuttable (ø1.0) -40℃ ~ +50°C	R2 Flex-proof High Flex Typ	0~590	ø0.5		SP-260U 4g

ø2.5	50cm non-cuttable -40℃ ~ +70°C	R10	0~45	ø0.125		SP-256 3g

	50cm non-cuttable -40℃ ~ +70°C Non-flexible Sleeve					SP-257 3g

ø3	2m cuttable (ø2.2) -40℃ ~ +70°C	R25	0~3600	ø1		SP-26F 19g

	2m cuttable (ø2.2) -40℃ ~ +50°C	R2 Flex-proof High Flex Typ	0~3600	ø1.13		SP-26FZ 19g

Through-beam｜Integrated Bracket Mount

Sensing Direction	Fiber Unit Length (Diameter) Ambient Temperature	Bending Radius (mm)	Sensing Distance (mm)*1	Optical Axis Diameter (mm)	Minimum Detectable Object	Model / Weight

Top	2m cuttable (ø2.2) -40℃ ~ +50°C	R2 Flex-proof	0~2200	ø1.13	ø0.005	SP-L452Z 30g

	2m cuttable (ø2.2) -40℃ ~ +50°C					SP-L453Z 30g

	2m cuttable (ø2.2) -40℃ ~ +50°C					SP-L454Z 30g

Top (Built-in Lens)	2m cuttable (ø2.2) -40℃ ~ +50°C		0~3600	ø3.5	ø0.2	SP-L451Z 30g

Side	2m cuttable (ø2.2) -40℃ ~ +50°C		0~1900	ø1.13	ø0.005	SP-L455Z 30g

Through-beam｜Narrow Beam / High Power

Sensing Direction	Beam Angle	Fiber Unit Length (Diameter) Ambient Temperature	Bending Radius (mm)	Sensing Distance (mm)*1	Optical Axis Diameter (mm)	Model / Weight

Side	Approx. 2°	2m cuttable (ø1.0) SP-217Z -40℃ ~ +50°C SP-217/219 -20℃ ~ +70°C	R10	0~3600	ø2.5	SP-219 8g

	Approx. 6°					SP-217 8g

			R2			SP-217Z 8g

	Approx. 3°	2m cuttable (ø1.0) -20℃ ~ +70°C	R10	0~3600	ø1.0	SP-219M 6g

Side	Approx. 6°	2m cuttable (ø1.0) -20℃ ~ +50°C	R2 Flex-proof	0~3600	ø2.8	SP-251 8g

Through-beam｜Flat Bracket Mount

Sensing Direction	Fiber Unit Length (Diameter) Ambient Temperature	Bending Radius (mm)	Sensing Distance (mm)*1	Optical Axis Diameter (mm))	Minimum Detectable Object	Model / Weight

Top	1m cuttable (ø1.0) -40℃ ~ +50°C	R2 Flex-proof	0~810	ø0.5	ø0.005	SP-452TZ 5g

	2m cuttable (ø1.3) -40℃ ~ +50°C		0~2900	ø1		SP-453TZ 15g

Flat Top	1m cuttable (ø1.0) -40℃ ~ +50°C		0~500	ø0.5		SP-454TZ 10g

	2m cuttable (ø2.2) -40℃ ~ +50°C		0~2900	ø1		SP-455TZ 25g

	2m cuttable (ø2.2) -40℃ ~ +50°C		0~750	ø1.13		SP-457TZ 20g

Side	1m cuttable (ø1.0) -40℃ ~ +50°C		0~740	ø0.5		SP-458TZ 5g

	1m cuttable(ø1.0) -40℃ ~ +70°C		0~630	ø0.7		SP-458TE 5g

Through-beam｜Sleeve Mount

Sensing Direction	Fiber Unit Length (Diameter) Ambient Temperature	Bending Radius (mm)	Sensing Distance (mm)*1	Optical Axis Diameter (mm)	Minimum Detectable Object	Model / Weight

Side	1m cuttable (ø1.3) -40℃ ~ +70°C	R25	0~520	ø0.6	ø0.005	SP-233
						5g
	2m cuttable (ø2.2) -40℃ ~ +70°C		0~1600	ø1		SP-235
						17g
Top	2m cuttable (ø2.2) -40℃ ~ +70°C		0~3600			SP-274
						24g
	1m cuttable (ø1.0) -40℃ ~ +70°C	R10	0~690	ø0.5		SP-276F
						10g
	50cm non-cuttable -40℃ ~ +70°C		0~45	ø0.125		SP-257
						3g

Through-beam｜High Flexibility

	ength (Diameter) Ambient Temperature	Bending Radius (mm)	Sensing Distance (mm)*1	Optical Axis Diameter (mm)	Minimum Detectable Object	Model / Weight

ø1.5	1m cuttable (ø1.0) -40℃ ~ +70°C	R4 High Flex Type	0~1200	ø0.7	ø0.005	SP-260
						3g
M3	1m cuttable (ø1.0) -40℃ ~ +70°C					SP-280
						6g
ø1.0	1m cuttable (ø1.0) -40℃ ~ +50°C	R2 Flex-proof High Flex Type	0~590	ø0.5		SP-259U
						4g
ø1.5	1m cuttable (ø1.0) -40℃ ~ +50°C					SP-260U
						4g
M3	1m cuttable (ø1.0) -40℃ ~ +50°C					SP-280U
						5g
M4	1m cuttable (ø1.0) -40℃ ~ +50°C		0~1800	ø2.3	-	SP-271U
						5g
	2m cuttable (ø1.0) -40℃ ~ +50°C	R1 Flex-proof	0~3600			SP-271TZ
						5g

Through-beam｜Oil & Chemical Resistant

Type	Beam Emission Direction	Fiber Unit Length (Diameter) Ambient Temperature	Minimum Bending Radius (mm)	Sensing Distance (mm)*1	Optical Axis Diameter (mm)	Model / Weight

Chemical-resistant	Top	2m cuttable (ø2.2) -40℃ ~ +70°C	R40	0~3600	ø3.7	SP-893
						71g
		2m cuttable (ø2.2) -40℃ ~ +70°C			ø6	SP-899
						70g
		2m cuttable (ø2.2) -40℃ ~ +70°C	R40		ø2.8	SP-897
						71g
	Side	2m cuttable (ø2.2) 0℃ ~ +60°C	R25*²		ø3.7	SP-897T
						35g
Oil-resistant		2m cuttable (ø2.2) -20℃ ~ +100°C	R2 Flex-proof		ø2.3	SP-881TZ
						30g
		2m cuttable (ø2.2) -20℃ ~ +100°C			ø4.3	SP-881MTZ
						55g

Through-beam｜High Temp Resistant

Heat Resist. Temp.	Fiber Unit Length (Diameter) Ambient Temperature	Bending Radius (mm)	Sensing Distance (mm)*1	Optical Axis Diameter (mm)	Minimum Detectable Object	Model / Weight

100℃	2m cuttable (ø2.2) -40至 +100°C	R5 Flex-proof	0~3600	ø1	ø0.005	SP-687Z
						25g
105℃	2m cuttable (ø2.2) -40至 +105°C	R25				SP-687A
						22g
150℃	2m cuttable (ø2.2) -40至 +150°C	R20	0~2700	ø1.5		SP-687H
						35g
180℃	2m cuttable (ø2.2) -60至 +180°C	R35				SP-689
						36g
300℃	2m non-cuttable -40至 +300°C	R25	0~1800	ø1		SP-685C
						66g
	2m non-cuttable -40至 +300°C					SP-685TZC
						43g
	2m non-cuttable -40至 +300°C					SP-685TZC-6
						43g

Through-beam｜Area Sensing

Sensing Method	Optical Axis Width	Fiber Unit Length (Diameter) Ambient Temperature	Bending Radius (mm)	Sensing Distance (mm)*1	Optical Axis Diameter (mm)	Model / Weight

Area Type	10	2m cuttable (ø2.2) -40至 +50°C	R2 Flex-proof	0~3600	10×3 (Attached with 1.0mm-wide slit)	SP-A223
						23g
	11	2m cuttable（ ø2.2） -40至 +50°C			11×2	SP-E212
						20g
	40	2m cuttable（ø2.2） -40至 +50°C			40×3	SP-E241
						30g
Array Type	5	2m cuttable (ø2.2) -40至 +70°C	R4	0~3600	Approx. 6×0.3	SP-A206
						20g
	10	2m cuttable (ø2.2) -40至 +70°C			Approx. 11×0.3	SP-A211
						20g
	40	2m cuttable (except for the 50mm spiral section)	R10		Approx. 40×0.25	SP-A241
						70g
	100	2m cuttable (except for the 50mm spiral section)			Approx. 100×0.25	SP-A2100
						110g

Through-beam｜Focusing Lens

Type	Ambient Temperature	Model / Weight	Sensing Distance (mm)*1	Applicable Optical Fiber
Long Sensing Distance Type, Beam Angle: Approx.15°	-40°C ~ +300°C	Economy： P-222g Approx.2g High-performance： P-412g Approx.2g	0~3600	SP-278TZ/278V/278/285C/289K
				SP-28F/287A
				SP-287Z
				SP-279
			0~1800	SP-278G/278MG/278TG/278MTG
Ultra-long Sensing Distance Type, Beam Angle: Approx.8°	-40°C ~ +70°C	P-24 约1g	0~3600	SP-278TZ/278V/278
				SP-28F
				SP-279
			0~1800	SP-278G/278MG/278TG/278MTG
Side-view Type with Mounting Hole	-40°C ~ +105°C	P-25 Approx.10g	0~3600	SP-278V/278
				SP-28F/288A
				SP-287Z
				SP-279
			0~1800	SP-278G

Retro-reflective｜Screw-fixed Mount

Dimension Shape Sensing Layout Fiber Unit Length(Diameter)
Ambient Temperature Bending Radius(mm) Sensing Distance(mm)*1 Minimum Detectable Object Model / Weight

M3 Thread Type Coaxial 50cm non-cuttable
SP-122X：-40~ +70°C
SP-125X：-40~ +50°C R25 0~130 ø0.005
Gold Wire SP-122X

4g

R10 0~100 SP-125X

4g

Hexagonal Type 1m cuttable (ø1.3×2)
-40~ +50°C R2
Flex-proof 0~400 SP-136TZ

7g

Thread Type 1m cuttable (ø1.3×2)
-40~ +50°C 0~450 SP-136FZ

6g

1m cuttable (ø1.3×2)
30cm spiral section
-40~ +50°C R10
SUS SP-136FG

6g

1m cuttable (ø1.3×2)
-40~ +70°C R25 0~550 SP-136FA

6g

M4 Thread Type Parallel 2m cuttable (ø1.3×2)
SP-167：-40~ +70°C
SP-167Z：-40~ +50°C R25 0~1100 SP-167

10g

R2
Flex-proof 0~770 SP-167Z

10g

Hexagonal Type 2m cuttable (ø1.3×2)
-40~ +50°C 0~640 SP-167TZ

10g

M6 Coaxial 1m non-cuttable
-40~ +50°C R10
SUS 0~400 SP-136TG

32g

Thread Type 2m cuttable (ø2.2×2)
-40~ +70°C R25 0~720 SP-126

18g

Parallel 2m cuttable (ø2.2×2)
-40~ +70°C 0~1100 SP-17F

21g

2m cuttable (ø2.2×2)
-40~ +70°C 0~1300 SP-162

21g

2m cuttable (ø2.2×2)
-40~ +50°C R2
Flex-proof 0~900 SP-168

21g

2m cuttable (ø2.2×2)
-40~ +50°C R0.5
Flex-proof SP-168V

25g

Hexagonal Type 2m cuttable (ø2.2×2)
-40~ +50°C R0.5
Flex-proof SP-168TZ

32g

Type Fiber Unit Length (Diameter)
Ambient Temperature Minimum Bending Radius (mm) Sensing Distance (mm)*1 Model / Weight

Dimension / Shape

M4 Hexagonal Type 2m cuttable (ø2.2×2)
-40至 +60°C R2
Flex-proof 0~710 SP-R168TZ

25g

1m non-cuttable
-40至 +60°C R10
SUS 0~710 SP-R168TG

32g

Thread Type 2m cuttable (ø2.2×2)
-40至 +60°C R2
Flex-proof 0~900 SP-R168

21g

2m cuttable (ø2.2×2)
-40至 +60°C R25 0~1100 SP-R17F

21g

1m non-cuttable
-40至 +60°C R10
SUS 0~900 SP-R168G

29g

Retro-reflective｜Cylindrical

Dimension	Fiber Unit Length (Diameter) Ambient Temperature	Bending Radius (mm)	Sensing Distance (mm)*1	Minimum Detectable Object	Model / Weight

ø1.5	1m non-cuttable -40~ +70°C	R10	0~27	ø0.005 Gold Wire	SP-147
					2g
	1m non-cuttable -40~+70°C	R4 High Flex Type	0~150		SP-150X
					3g
ø2	1m cuttable (ø1.0×2) -40~ +50°C	R2 Flex-proof High Flex Type	0~140		SP-150U
					4g
ø2.5	50cm non-cuttable -40~ +70°C	R25	0~72		SP-123X
					4g
ø3	2m cuttable (ø1.3×2) SP-15F： -40~ +70°C SP-15FZ：-40~ +50°C		0~1100		SP-15F
					8g
		R2 Flex-proof High Flex Type	0~770		SP-15FZ
					8g
	50cm non-cuttable -40~ +70°C	R25	0~830		SP-124X
					4g
	50cm non-cuttable -40~ +70°C	R4	0~68		SP-146X
					4g
	2m cuttable (ø1.0×2) -40~ +70°C	R4 High Flex Type	0~290		SP-149
					7g

Retro-reflective｜Integrated Bracket Mount

Sensing Direction	Optical Axis Height	Fiber Unit Length(Diameter) Ambient Temperature	Bending Radius(mm)	Sensing Distance(mm)*1	Minimum Detectable Object	Model / Weight
Top	10	2m cuttable (ø2.2) -40~ +50°C	R2 Flex-proof	0~760	ø0.005	SP-L342Z
						25g

Retro-reflective｜Narrow Beam / High Power

Sensing Direction	Beam Angle	Fiber Unit Length(Diameter) Ambient Temperature	Bending Radius(mm)	Sensing Distance(mm)*1	Minimum Detectable Object	Model / Weight
Top	Approx. 8°	2 m cuttable ( ø2 . 2) - 40~ +50 °C	R2 Flex-proof	0~2300	ø0.3 Copper Wire (Vert.)	SP-141
						23g
		1m non-cuttable (ø1.0) -40~ +50°C	R10 SUS	0~2700		SP-141G
						50g

Retro-reflective｜Small Spot

Type	Spot Diameter	Focal Distance	Fiber Unit Length(Diameter) Ambient Temperature	Bending Radius(mm) (mm)	Model / Weight
Adjustable Spot	ø0.9~3.5	10~30	2m cuttable (ø1.3×2) -40~+70°C	R25	SP-111
					5g

Type	Spot Diameter	Focal Distance	Fiber Unit Length(Diameter) Ambient Temperature	Bending Radius(mm)	Model / Weight
Small Spot	ø0.1	5	50cm non-cuttable -40至 +70°C	R25	SP-121
					2g

Retro-reflective｜Focusing Lens

Type	Spot Diameter	Focal Distance	Lens		Fiber Unit
Type	Spot Diameter	Focal Distance	Model / Weight	Ambient Temperature	Bending Radius(mm)	Shape(mm)	Model
Small Spot	ø0.2	7±2	Economy P-12HA 1g Economy P-31HA 1g High-performance P-33HA 1g	-30~+70°C P-12HA -40~+70°C P-31HA -30~+70°C P-33HA	R25		SP-122X
	ø0.1				R10		SP-125X
	ø0.4				R25		SP-136FA
					R10 SUS		SP-136FG
					R2 Flex-proof		SP-136FZ
					R10 SUS		SP-136TG
					R2 Flex-proof		SP-136TZ

Type	Spot Diameter	Focal Distance	Lens		Fiber Unit
			Model / Weight	Ambient Temperature	Bending Radius(mm)	Shape(mm)	Model
Small Spot	ø0.5	15±2	P-14HA 2g	-30~ +70°C	R25		SP-136FA
					R10 SUS		SP-136FG
					R2 Flex-proof		SP-136FZ
					R10 SUS		SP-136TG
					R2 Flex-proof		SP-136TZ
	ø1.0	35±3	P-16HA 5g	-40~ +70°C	R25		SP-122X
							SP-136FA
	ø2.0				R10 SUS		SP-136FG
					R2 Flex-proof		SP-136FZ
					R2 Flex-proof		SP-136TZ

Type	Spot Diameter	Focal Distance	Lens		Fiber Unit
			Model / Weight	Ambient Temperature	Bending Radius(mm)	Shape(mm)	Model
Side-view Adjustable Spot	ø0.5~3	8~30	P-15HA 2g	-30~ +70°C	R25		SP-136FA
					R10 SUS		SP-136FG
					R2 Flex-proof		SP-136FZ

Type	Spot Diameter			Fiber Unit
		Model / Weight	Ambient Temperature	Bending Radius(mm)	Sensing Dist.(mm)*¹	Shape(mm)	Model
Parallel Beam	Spot Diameter ≈Ø4 (Within Sensing Distance 0~20mm)	P-13HA 2g	-30至 +70°C	R25	0~65		SP-136FA
				R10 SUS	0~45		SP-136FG
				R2 Flex-proof			SP-136FZ
				R10 SUS	0~40		SP-136TG
				R2 Flex-proof			SP-136TZ

Type	Ambient Temperature	Model / Weight	Sensing Distance(mm)*¹	Applicable Optical Fiber
High-temperature Ultra-long Distance Lens ²	-60°C~ +350°C	P-61S-3 20g	0~3600	SP-278TZ/278V/278/279
				SP-689/687Z/687A/687H
				SP-28F
			0~1600	SP-685C/SP-584C

Limited Reflective Type

Direction	Fiber Unit Length(Diameter)Ambient Temperature	Bending Radius(mm)	Sensing Distance(mm)*¹	Optical Axis Diameter(mm)	Minimum Detectable Object	Model / Weight
Side	2m cuttable (ø1.0×2) -40~ +70°C	R10	Sensing Center at 3mm	Optical Axis Dia.≈Ø4.5 / Ø3.5(At 3mm distance)	ø0.005 Gold Wire	SP-138
						6g
Flat	2m cuttable (ø1.0×2) -40~ +70°C		0~4	-	ø0.08 Copper Wire	SP-139V
						5g
	2m cuttable (ø1.0×2) -40~ +70°C		6中心	ø1.5 (At 6mm distance)	-	SP-139
						5g
	2m cuttable (ø2.2×2) -40~ +60°C	R25	0~89	-	-	SP-139L
						20g
	2m cuttable (ø2.2×2) -40~ +70°C	R5	0~25	-	-	SP-139S
						20g
	2m cuttable (ø2.2×2) -40~ +70°C	R25	0~14	-	-	SP-139R
						20g
Top	2m cuttable (ø2.2×2) -40~ +70°C	R25	0~150	-	-	SP-141S
						25g

Retro-reflective｜Flat Bracket Mount

Direction	Fiber Unit Length(Diameter) Ambient Temperature	Bending Radius(mm) (mm)	Sensing Distance(mm)*¹	Minimum Detectable Object	Model / Weight
Flat	1m cuttable (ø1.0×2) -40至 +50°C	R2 Flex-proof	0~120	ø0.005 Gold Wire	SP-342TZ
					5g
	2m cuttable (ø2.2×2) -40至 +50°C		0~500		SP-343TZ
					24g
	2m cuttable (ø2×2.2） -40至 +50°C		0~120		SP-344TZ
					22g
Top	1m cuttable (ø1.0×2） -40至 +50°C		0~160		SP-345TZ
					3g
Side	1m cuttable（ ø1.0×2） -40至 +50°C				SP-348TZ
					4g

Retro-reflective｜Sleeve Mount

Direction	Fiber Unit Length(Diameter) Ambient Temperature	Bending Radius(mm)	Sensing Distance(mm)*¹	Minimum Detectable Object	Model / Weight
Coaxial Narrow Beam (10°)	50cm non-cuttable -40至 +70°C	R25	0~72	ø0.005 Gold Wire	SP-123X
					4g
Side	2m cuttable（ ø1.0×2） -40至 +70°C	R10	0~180		SP-132
					5g
	1m cuttable（ ø2.2×2） -40至 +70°C	R25	0~320		SP-134
					10g
Top	2m cuttable（ ø1.3×2） -40至 +70°C		0~330		SP-144
					8g
	50cm non-cuttable -40至 +70°C	R4	0~68		SP-146X
					4g
	1m non-cuttable -40至 +70°C	R10	0~27		SP-147
					2g
	1m cuttable (ø1.0) -40至 +70°C		0~390		SP-277F
					10g
	2m cuttable（ ø1.3×2） -40至 +70°C	R25	0~330		SP-164
					10g
	2m cuttable（ ø1.3×2） -40至 +70°C				SP-164T
					10g
	2m cuttable（ ø1.3×2） -40至 +50°C	R2 Flex-proof	0~290		SP-164Z
					10g
	50cm non-cuttable -40至 +70°C	R4	0~68		SP-166X
					5g

Retro-reflective｜High Flexibility

Dimension	Fiber Unit Length (Diameter) Ambient Temperature	Bending Radius (mm)	Sensing Distance (mm)*1	Minimum Detectable Object	Model / Weight
ø3	2m cuttable（ ø1.0×2） -40至 +70°C	R4 High Flex Type	0~290	ø0.005 Gold Wire	SP-149
					7g
M4	2m cuttable（ ø1.0×2） -40至 +70°C				SP-169
					8g
ø3	1m cuttable（ ø1.0×2） -40至 +50°C	R2 Flex-proof High Flex Type	0~140		SP-149U
					4g
ø2	1m cuttable（ ø1.0×2） -40至 +50°C				SP-150U
					4g
M3	1m cuttable（ ø1.0×2） -40至 +50°C				SP-170U
					4g
ø1.5	1m non-cuttable -40至 +70°C	R4 High Flex Type	0~150		SP-150X
					3g
M3	1m non-cuttable -40至 +70°C				SP-170X
					3g

Retro-reflective｜Oil & Chemical Resistant

Type Beam Emission Direction Fiber Unit Length(Diameter)
Ambient Temperature Min. Bending Radius(mm) Sensing Distance(mm)*¹ Standard Target to Detect Model / Weight

Oil & Chemical Resistant Top 2m cuttable
(ø1.3×2)
-40~ +70°C R40 0~310 — SP-792

32g

2m cuttable
(ø1.3×2)
-40~ +60°C 0~20 200×200mm
t=0.7mm
Glass Substrate SP-798P

75g

2m cuttable
(ø1.3×2)
-40~ +85°C SP-798S

90g

Retro-reflective｜High Temp Resistant

Heat Resistant Temperature	Fiber Unit Length(Diameter) Ambient Temperature	Bending Radius(mm)	Sensing Distance(mm)*¹	Minimum Detectable Object	Model / Weight
350℃	1m non-cuttable -30至 +350°C	R25	0~650	ø0.005 Gold Wire	SP-582C
					24g
300℃	1m non-cuttable -40至 +300°C		0~770		SP-583C
					29g
	1m non-cuttable -40至 +300°C				SP-584C
					23g
	1m non-cuttable -40至 +300°C				SP-584TZC
					22g
	1m non-cuttable -40至 +300°C				SP-584TZC-6
					22g
250℃	2m non-cuttable -40至 +250°C		0~86		SP-139LK
					70g
	1m non-cuttable -40至 +250°C		0~150		SP-139K
					45g
105℃	2m cuttable (ø2.2×2) -40至 +105°C		0~1100		SP-586A
					21g
200℃	1m non-cuttable -40至 +200°C	R8	0~790		SP-588K
					15g
150℃	2m cuttable (ø2.2×2) -40至 +150°C	R20	0~720		SP-586H
					35g
100℃	2m cuttable (ø2.2×2) -40至 +100°C	R5 Flex-proof	0~740		SP-586Z
					25g
180℃	2m cuttable (ø2.2×2) -60至 +180°C	R35	0~860		SP-588
					33g
	2m cuttable (ø2.2×2) -40至 +180°C		0~150		SP-139H
					45g

Retro-reflective｜Area Sensing

Detection Method Spot Width(mm) Fiber Unit Length(Diameter)Ambient Temperature Bending Radius(mm) Sensing Distance(mm)*¹ Minimum Detectable Object Model / Weight

Area 15
(At 15mm distance) 2m cuttable (ø2.2)
-40~ +70°C R25 0~200 ø0.1 Gold Wire SP-112

19g

Array 10
(At 4mm distance) 2m cuttable (ø2.2×2)
-40~ +70°C R4 0~1200 SP-A106D

20g

15
(At 4mm distance) 2m cuttable
-40~ +70°C SP-A111D

20g

Retro-reflective｜Liquid Level

Detection Method	Transparent Pipe Diameter	Beam Axis	Fiber Unit Length(Diameter) Ambient Temperature	Bending Radius(mm)	Accessories	Model / Weight
Pipe Mount Type	ø4~ø26	1	2m cuttable（ø1.0×2） SP-196S（ ø2.2×2） SP-196:-40~ +70°C SP-196S:-40~ +70°C SP-196Z:-40~ +50°C SP-196HA:-40~ +105°C *When the fiber unit is frequently used in high-temperature environments, the recommended maximum ambient temperature during operation is 90℃.	R10	End Cap×2 Anti-slip Rubber×2 Gasket×2 Screw×2 Nut×2	SP-196
						7g
				R2 Flex-proof		SP-196Z
						7g
				R10		SP-196HA
						7g
				R5	Band Clamp ×2 Anti-slip Rubber ×2 Fiber Cutter ×1	SP-196S
						23g
Penetration Type	-	-	2m cuttable (ø1.3×2) SP-194：-40~ +70°C SP-194Z：-40~ +50°C	R25	-	SP-194
						78g
				R0.5 Flex-proof		SP-194Z
						78g

Download catalogue

SP SeriesOverview

Download

Service

Overview Products Lineup Specs Dimensions Model

Download

Recommended Series

You may also be interested in the following informationView more>>

FX-N425 Series Fiber Optic Sensor Catalogue

FX-N10 Series High-Precision Digital Fiber Optic Sensor Catalogue

SP Series High-Performance Fiber Optic Sensor Catalogue

Fibre Optic Sensors

High Performance Type- SP Series

Download

Service

Recommended Series

You may also be interested in the following informationView more>>

Download

Service Support

+86-755-83330055

Recommended Content

Fibre Optic Sensors series

Fibre Optic Sensors

File waiting to be downloaded ×

Dimension	Shape	Sensing Layout	Fiber Unit Length(Diameter) Ambient Temperature	Bending Radius(mm)	Sensing Distance(mm)*1	Minimum Detectable Object	Model / Weight

M3	Thread Type	Coaxial	50cm non-cuttable SP-122X：-40~ +70°C SP-125X：-40~ +50°C	R25	0~130	ø0.005 Gold Wire	SP-122X
							4g
				R10	0~100		SP-125X
							4g
	Hexagonal Type		1m cuttable (ø1.3×2) -40~ +50°C	R2 Flex-proof	0~400		SP-136TZ
							7g
	Thread Type		1m cuttable (ø1.3×2) -40~ +50°C		0~450		SP-136FZ
							6g
			1m cuttable (ø1.3×2) 30cm spiral section -40~ +50°C	R10 SUS			SP-136FG
							6g
			1m cuttable (ø1.3×2) -40~ +70°C	R25	0~550		SP-136FA
							6g
M4	Thread Type	Parallel	2m cuttable (ø1.3×2) SP-167：-40~ +70°C SP-167Z：-40~ +50°C	R25	0~1100		SP-167
							10g
				R2 Flex-proof	0~770		SP-167Z
							10g
	Hexagonal Type		2m cuttable (ø1.3×2) -40~ +50°C		0~640		SP-167TZ
							10g
M6		Coaxial	1m non-cuttable -40~ +50°C	R10 SUS	0~400		SP-136TG
							32g
	Thread Type		2m cuttable (ø2.2×2) -40~ +70°C	R25	0~720		SP-126
							18g
		Parallel	2m cuttable (ø2.2×2) -40~ +70°C		0~1100		SP-17F
							21g
			2m cuttable (ø2.2×2) -40~ +70°C		0~1300		SP-162
							21g
			2m cuttable (ø2.2×2) -40~ +50°C	R2 Flex-proof	0~900		SP-168
							21g
			2m cuttable (ø2.2×2) -40~ +50°C	R0.5 Flex-proof			SP-168V
							25g
	Hexagonal Type		2m cuttable (ø2.2×2) -40~ +50°C	R0.5 Flex-proof			SP-168TZ
							32g

Detection Method	Spot Width(mm)	Fiber Unit Length(Diameter)Ambient Temperature	Bending Radius(mm)	Sensing Distance(mm)*¹	Minimum Detectable Object	Model / Weight
Area	15 (At 15mm distance)	2m cuttable (ø2.2) -40~ +70°C	R25	0~200	ø0.1 Gold Wire	SP-112
						19g
Array	10 (At 4mm distance)	2m cuttable (ø2.2×2) -40~ +70°C	R4	0~1200		SP-A106D
						20g
	15 (At 4mm distance)	2m cuttable -40~ +70°C				SP-A111D
						20g

Fibre Optic Sensors

High Performance Type- SP Series

Download

Service

Recommended Series

You may also be interested in the following informationView more>>

Download

Service Support

+86-755-83330055

Recommended Content

Fibre Optic Sensors series

Fibre Optic Sensors

Login

File waiting to be downloaded ×
