| Model | SK-H400 | SK-H500 | SK-H600 | SK-H800 | SK-H1000 | SK-H1200 | SK-H1500 | SK-H1800 | SK-H2000 | SK-H2200 | SK-H2500 |
| Effective length (mm) | 300 | 400 | 500 | 700 | 900 | 1100 | 1400 | 1700 | 1900 | 2100 | 2400 |
| Ionic balance | ±30 V | ||||||||||
| De-static speed | 0.1 s | ||||||||||
| Input voltage | 20-36 VDC | ||||||||||
| Voltage operating mode | Pulse AC | ||||||||||
| Rated power | 24 W | ||||||||||
| Rated current | 1 A | ||||||||||
| Frequency setting | 10, 20, 50, 60, 100 Hz | ||||||||||
| Working distance | 50-1500 mm | ||||||||||
| Recommended installation distance | 300 mm | ||||||||||
| Connecting sensor | Available | ||||||||||
| Air connector size | d＞8 mm | ||||||||||
| Operating air pressure | 0.1 Mpa-0.5 Mpa | ||||||||||
| Discharge electrode replaceable | Available | ||||||||||
| Ambient temperature | -10 to +45 °C | ||||||||||
| Ambient humidity | 10 to 65 % RH | ||||||||||
| Cable | OW-SKH3000 (standard) | ||||||||||
temperature (23±3)°C; humidity (50±5)%; test voltage 1 KV-100 V; test distance 50 mm; test instrument: 3M711
